Cassini Photos Show Saturn's Hexagon at Its North Pole

OK, I'm not a space scientist, but I own a telescope and I can name a few stars. So I have an amateur's interest in this stuff. I don't usually post items like this, but to me this was too weird to pass up. No media or politics here, so if you don't care about this, just move on.

This is Saturn's north pole, as captured by cameras aboard NASA's Cassini spacecraft. The photos the spacecraft took show an intriguing hexagon shape crowning the planet. While the unique phenomena has been known since the 1980s, these are the most detailed images of the event.

The new images of the hexagon, whose shape is the path of a jet stream flowing around the north pole, reveal concentric circles, curlicues, walls and streamers not seen in previous images. Images and the three-frame animation are available here, here and here.

The last visible-light images of the entire hexagon were captured by NASA's Voyager spacecraft nearly 30 years ago, the last time spring began on Saturn. After the sunlight faded, darkness shrouded the north pole for 15 years. Much to the delight and bafflement of Cassini scientists, the location and shape of the hexagon in the latest images match up with what they saw in the Voyager pictures.

"The longevity of the hexagon makes this something special, given that weather on Earth lasts on the order of weeks," said Kunio Sayanagi, a Cassini imaging team associate at the California Institute of Technology, in a press release. "It's a mystery on par with the strange weather conditions that give rise to the long-lived Great Red Spot of Jupiter."

The hexagon was originally discovered in images taken by the Voyager spacecraft in the early 1980s. It encircles Saturn at about 77 degrees north latitude and has been estimated to have a diameter wider than two Earths. The jet stream is believed to whip along the hexagon at around 100 meters per second (220 miles per hour).

Early hexagon images from Voyager and ground-based telescopes suffered from poor viewing perspectives. Cassini, which has been orbiting Saturn since 2004, has a better angle for viewing the north pole. But the long darkness of Saturnian winter hid the hexagon from Cassini's visible-light cameras for years. Infrared instruments, however, were able to obtain images by using heat patterns. Those images showed the hexagon is nearly stationary and extends deep into the atmosphere. They also discovered a hotspot and cyclone in the same region.

The visible-light cameras of Cassini's imaging science subsystem, which have higher resolution than the infrared instruments and the Voyager cameras, got their long-awaited glimpse of the hexagon in January, as the planet approached equinox. Imaging team scientists calibrated and stitched together 55 images to create a mosaic and three-frame movie. The mosaics do not show the region directly around the north pole because it had not yet fully emerged from winter night at that time.

Scientists are still trying to figure out what causes the hexagon, where it gets and expels its energy and how it has stayed so organized for so long. They plan to search the new images for clues, taking an especially close look at the newly identified waves that radiate from the corners of the hexagon -- where the jet takes its hardest turns -- and the multi-walled structure that extends to the top of Saturn's cloud layer in each of the hexagon's six sides. Scientists are also particularly intrigued by a large dark spot that appeared in a different position in a previous infrared image from Cassini. In the latest images, the spot appears in the 2 o'clock position.

Because Saturn does not have land masses or oceans on its surface to complicate weather the way Earth does, its conditions should give scientists a more elementary model to study the physics of circulation patterns and atmosphere, said Kevin Baines, an atmospheric scientist at NASA's Jet Propulsion Laboratory, Pasadena, Calif., who has studied the hexagon with Cassini's visual and infrared mapping spectrometer.

"Now that we can see undulations and circular features instead of blobs in the hexagon, we can start trying to solve some of the unanswered questions about one of the most bizarre things we've ever seen in the solar system," Baines said. "Solving these unanswered questions about the hexagon will help us answer basic questions about weather that we're still asking about our own planet."
